為各企業量身定制非標高壓噴淋清洗機，高壓噴淋清洗線，不間斷工作。適用于各個行業的拉伸件、壓鑄件清洗作業?？梢约友b電加熱系統，可以設置恒溫裝置，廣泛用于:五金制品行業、汽車零件行業等，投入成本低。

Tailor made non-standard high-pressure spray cleaning machines and high-pressure spray cleaning lines for various enterprises, ensuring uninterrupted operation. Suitable for cleaning stretching and die-casting parts in various industries. It can be equipped with an electric heating system and a constant temperature device, widely used in industries such as hardware products and automotive parts, with low investment costs.

特點

Characteristics

1.速度快，效果統一。

1. Fast speed and uniform effect.

2.具有清洗液噴洗、清水噴淋漂洗、吹水、熱風吹干等功能的新穎連續式清洗設備。

2. A novel continuous cleaning equipment with functions such as spraying cleaning solution, rinsing with clean water, blowing water, and drying with hot air.

3.清洗機工作效率、溫度可調。

3. The efficiency and temperature of the cleaning machine can be adjusted.

4.它對生產效率大大提高，節約成本。

4. It greatly improves production efficiency and saves costs.

清洗機的清洗步驟

Cleaning steps of the cleaning machine

各種噴淋清洗機的結構、作用可能有所不同，但主要工藝流程還是相同的，每個實際操作階段都是存在的重要性，因此不僅不能忽視，而且一定要按照規定完成實際操作，確保理想的清洗效果。

The structure and function of various spray cleaning machines may vary, but the main process flow is still the same. The importance of each actual operation stage cannot be ignored, and it is necessary to complete the actual operation according to the regulations to ensure the ideal cleaning effect.

噴淋清洗機清洗的主要過程是濕熱起泡，是將工件放入50～60℃的清洗液中浸泡，對工件進行初步清洗。這樣做的意義很簡單，為了減少噴淋清洗后的長度，提高清洗質量。

The main process of cleaning with a spray cleaning machine is wet and hot foaming, which involves immersing the workpiece in a cleaning solution at 50-60 ℃ for preliminary cleaning. The significance of doing so is simple, to reduce the length after spray cleaning and improve the cleaning quality.

之后是噴淋清洗機，立即組裝在清洗槽底部的超聲波換能器，與外部超聲波換能器形成超聲波清洗機。然后，用清洗液在40～50℃對工件進行超聲波清洗。

Next is the spray cleaning machine, which immediately assembles an ultrasonic transducer at the bottom of the cleaning tank and forms an ultrasonic cleaning machine with an external ultrasonic transducer. Then, use cleaning solution to perform ultrasonic cleaning on the workpiece at 40-50 ℃.

下一步是噴涂并清洗防銹水，拔出噴涂儲罐的防銹水，并根據噴嘴清潔工件。一方面是因為去除了工件表面的清洗液，另一方面是因為對工件進行了防銹處理。

The next step is to spray and clean the anti rust water, remove the anti rust water from the spray tank, and clean the workpiece according to the nozzle. On the one hand, it is because the cleaning solution on the surface of the workpiece has been removed, and on the other hand, it is because the workpiece has been treated with rust prevention.

由于噴淋清洗機后工件表面會有大量水滴，如果立即將此類物質放入干燥通道，其表面將保留液態汞太長時間，因此可以在一個槽中干燥，通過離心風機輕輕干燥工件表面水，然后進入干燥通道。

Due to the large amount of water droplets on the surface of the workpiece after the spray cleaning machine, if such substances are immediately placed in the drying channel, the surface will retain liquid mercury for too long. Therefore, it can be dried in a tank by gently drying the surface water of the workpiece with a centrifugal fan, and then entering the drying channel.

干燥通道包含電熱管，并外部使用保溫隔熱材料，因此根據離心風機底部的排氣、頂部的空氣進入的方法來產生一個暖風循環系統，使環境溫度在干燥通道中均勻分布，然后用噴淋清洗機將清洗后的工件擦干。

The drying channel contains electric heating tubes and is externally insulated with thermal insulation materials. Therefore, a warm air circulation system is generated by the exhaust from the bottom of the centrifugal fan and the air entering from the top, so that the ambient temperature is evenly distributed in the drying channel. Then, the cleaned workpiece is dried with a spray cleaning machine.
